corrugated pipe machine
Corrugated tube machine
Corrugated pipe machine, Extrusion line for single wall / double wall corrugated pipes
Corrugator Model C15 C58 C65 C75 C90 C125 C160 C250 C700
Max. O.D. (mm) 15 58 65 75 90 125 160 250 700
Min. I.D. (mm) 4.5 8 10 30 30 30 32 32 150
corrugated tube machinery Double wall corrugated pipe machine



Double wall corrugated pipe machine

Extrusion line for the production of single-wall and double wall corrugated tubes and pipes made of PE, PP, PVC, PA, EVA, PVDF, TPE etc.

Main applications:
Building industry: electrical conduit & sanitary hose duct/flexible pipe for siphon, PP-PE-PVC-PA
Automotive industry: Fuel line pipe & wiring harness tubing, PP-PA6-PA11-PA12-PA612
Medical industry: breathing tubes, LLDPE,EVA
Civil works industry: double wall cable conduit, HDPE
Agriculture: drainage pipe, HDPE, PVC

The range includes: Water cooling corrugator, Blow forming system corrugator, Vacuum forming system corrugator, Sequential mode corrugator, Variable Chain Length corrugator. corrugators systems for pipes with interior diameters from 4.5 mm and exterior diameter ranging up to OD700mm in a variety of thermoplastics.


two types of pipe corrugator:
Internal blow moulding
Vacuum forming

Blow Moulding:
This technology consist of blowing low pressure (0,1-1,5 bar) through the die head spider into the center of the continuously extruded hot plastic tube. The air is retained by a plug with metallic or silicone washers.
The hot plastic material is expanded by the internal air pressure against the corrugation machined in the mould blocks which chill and holds the tube against the moulds to provide the desired geometry. Corrugated products formed by internal air must have constant I.D. dimension.

Vacuum forming:
This technology consists of pulling the hot plastic tube against the mould blocks by vacuum suction applied through the moulds applied to the plastic tube outside diameter surface. Vacuum from the moulds keep the tube against the moulds to provide the desired geometry. Corrugated products formed by vacuum may have variable I.D. dimensions.

Applications

    cable wire protection (in the building, telecommunications and car industry)
    TV, telephone
    glass fiber
    electricity
    control and computer cables
    automobiles, machines and airplanes
    medical applications
    washing machines
    dishwashers



Machinery for production of siphon corrugated pipe
Machine for medical corrugated tubing
Machine for corrugated flat/round PE/PP post tensioning duct
Machinery for corrugated PA tubing
Extrusion line for pre-wired corrugated PP conduit
Double layer corrugated pipe extrusion machine
Double wall HDPE electrical duct extrusion line
Corrugated duo pipe extrusion machine
Multilayer corrugated PA tube machine
flat corrugated pipe/duct machine
perforated corrugated pipe machine
Extrusion line for corrugated sink waste pipe
